Describe in words the surface whose equation is given:

\[ \phi = \dfrac{\pi}{4} \]

Choose the correct answer:

– The upper half of the right circular cone whose vertex lies at the origin and axis at the positive z axis.

– The plane perpendicular to the xz plane crossing z = x, where $x \geq 0$.

– The plane perpendicular to the xz plane crossing y= x, where $x \geq 0$.

– The bottom of the right circular cone whose vertex lies at the origin and axis at the positive z axis.

– The plane perpendicular to the $yz$ plane crossing z = y, where $y \geq 0$.

This problem aims to describe the surface of a circular cone whose equation is given. To better understand the problem, you should be familiar with cartesian coordinate systems, spherical coordinates, and cylindrical coordinate systems.

Spherical coordinates are the 3 coordinates that determine the location of a point in a 3 dimensional trajectory. These 3 coordinates are the length of its internal radius vector r, the angle $\theta$ between the vertical plane having this vector and the x axis, and the angle $\phi$ between this vector and the horizontal x-y plane.

Expert Answer

We can relate cylindrical coordinates with spherical coordinates such that if a point contains cylindrical coordinates $\left( r, \theta, z \right)$, $\left( r, \theta, z \right)$, then these equations describe the association between cylindrical and spherical coordinates. $r = \rho \sin\phi$ These type of equations are used to convert from $\phi = \theta$, spherical coordinates to cylindrical $z = \rho \sin\phi$ coordinates.

Spherical Coordinates are given as:

\[x = Rcos\theta sin\phi = \dfrac {Rcos\theta}{\sqrt{2}} \]

\[y = Rsin\theta sin\phi = \dfrac {Rsin\theta} {\sqrt{2}} \]

\[z = Rcos\phi = \dfrac {R} {\sqrt{2}} \]

\[ x^2 + y^2 = \dfrac {R^2} {2} = z^2 \]

\[ z^2 = x^2 + y^2 \]

\[ z = \sqrt{x^2 + y^2} \]

Now,

$z = +\sqrt{x^2 + y^2}$ is the upper bond and $z = -\sqrt{x^2 + y^2}$ is the lower bond.

We have only had the upper part of the cone that is $z = +\sqrt{x^2 + y^2}$.

if $\phi$ is representing the lower part of the cone, then the correct option comes out to be $1$.

Numerical Result

The correct option is the option no. $1$ that is:

  • The upper half of the right circular cone with vertex at the origin and axis at the positive $z$ axis.

Example

An equation for a surface is given, elaborate it in verbal context: $ \phi = \dfrac{\pi}{3} $.

Spherical Coordinates are  $ \phi = \dfrac{\pi}{3} $:

\[ cos\phi = cos \left( \dfrac{\pi}{3}\right) = \dfrac{1}{2}  \hspace{3ex} … (1) \]

\[ x = \rho sin\phi cos\theta \]

\[ cos^2 \phi = \dfrac{1}{4} \hspace{3ex} … (2) \]

\[ y = \rho sin\phi sin\theta \]

\[ \rho^2cos^2\theta = \dfrac{1}{4} \rho^2 \hspace{3ex} … (3) \]

\[ z^2 = \dfrac{1}{4}(x^2 + y^2 + z^2) \hspace{3ex} … (4) \]

\[ x^2 + y^2 + z^2 = \rho^2 \]

\[ 4z^2 = x^2 + y^2 + z^2 \]

\[ 3z^2 = x^2 + y^2 \]

so $3z^2 = x^2 + y^2$ is a double cone.
