What is the position vector r(t) as a function of angle Θ(t). Give your answer about R, Θ(t), and the unit vectors x and y corresponding to the coordinate system.

1. Find $\theta (t)$ at an arbitrary time t for uniform circular motion. Present the answer in terms of $\omega$ and t.
2. Find position vector r at time. Present the answer in terms of $R$ and unit vectors x and y.
3. Find the formula for the position vector of a particle that starts with $(thatis,(x_0,y_0)=(0,R))$ on the positive y axis and then constantly moves in $\omega$. Show the answer in terms of R, $\omega$ ,t ,and unit vectors x and y.

The first part of the question aims to represent the position vector in terms of $\theta (t)$ and $R$. The second part of the question seeks to find $\theta (t)$ for an arbitrary time $t$ for circular motion. The third part of the question aims to find position vector $r$ at time $t$. The last part of the question seeks to find position vectors in terms of $\omega$, $R$, and $t$.

Position vectors are used to indicate the position of a particular body. Knowing the part of the body is essential for explaining the movement of the body. A position vector is a vector that represents the position or position of any point with respect to a datum such as an origin. Position vector always points to a specific topic from the source of this vector. For issues that move along a straight path, the position vector that matches the way is most helpful. The velocity of a point is equal to the velocity at which the magnitude of the vector changes over time, resulting in a vector placed along a line.

Expert Answer

Part (1): Position vector $r(t)$ as a function of angle $\theta (t)$ in terms of $R$ and $\theta (t)$ is shown as:

$$r(t)=R\cos (\theta t)\overrightarrow{i}+R\sin (\theta t)\overrightarrow{j}$$

Part(2): $\theta (t)$ for uniform circular motion at an arbitrary time $t$ in term of $\omega$ and $t$ is shown as:

$$\theta (t)=\omega t$$

Part(3): Position vector $r(t)$ at time $t$ in terms of the $R$ and position vector $x$ and $y$.

$$r(t)=R\cos (\omega t)\overrightarrow{i}+R\sin (\omega t)\overrightarrow{j}$$

Part(4): Position vector $r$ for a particle that starts on the positive $y$ axis and moves with constant $\omega$.

$$r=Ri$$

$$ry(t)=-R\sin (\omega t)\overrightarrow{i}+R\cos (\omega t)\overrightarrow{j}$$

Numerical Answers

(1)

Position vector in term of $R$ and $\theta (t)$ is calculated as:

$$r(t)=R\cos (\theta t)\overrightarrow{i}+R\sin (\theta t)\overrightarrow{j}$$

(2)

$\theta$ for uniform circular motion at an arbitrary time is shown as:

$$\theta (t)=\omega t$$

(3)

Position vector $r(t)$ at time $t$ in terms of the $R$ and position vector $x$ and $y$ is calculated as:

$$r(t)=R\cos (\omega t)\overrightarrow{i}+R\sin (\omega t)\overrightarrow{j}$$

(4)

Position vector $r$ for a particle is shown as:

$$r=Ri$$

$$ry(t)=-R\sin (\omega t)\overrightarrow{i}+R\cos (\omega t)\overrightarrow{j}$$

Example

-What is the position vector $r(t)$ as a function of angle $\theta (t)$.

-Find position vector $r$ at time.

Solution

(a): Position vector $r(t)$ as a function of angle $\theta (t)$ in term of $R$ and $\theta (t)$ is shown as:

$$r(t)=R\cos (\theta t)\overrightarrow{i}+R\sin (\theta t)\overrightarrow{j}$$

(b): Position vector $r(t)$ at time $t$ in term of the $\omega$ and $R$ is given as:

$$r(t)=R\cos (\omega t)\overrightarrow{i}+R\sin (\omega t)\overrightarrow{j}$$
