Volume of Cylinders – Explanation & Examples

Volume of CylindersThe volume of a cylinder is the measure of the amount of space occupied by a cylinder or the measure of the capacity of a cylinder.

This article will show you how to find the volume of a cylinder by using cylinder volume formula.

In geometry, a cylinder is a 3-dimensional shape with two equal, and parallel circles joined by a curved surface.

cylinder

The distance between the circular faces of a cylinder is known as the height of a cylinder. The top and bottom of a cylinder are two congruent circles whose radius or diameter are denoted as ‘r’ and ‘d’, respectively.

How to Find the Volume of a Cylinder?

To calculate the volume of a cylinder, you need the radius or diameter of the circular base or top and a cylinder’s height.

The volume of a cylinder is equal to the product of the area of the circular base and the height of the cylinder. The volume of a cylinder is measured in cubic units.

Calculation of the volume of a cylinder is useful when designing cylindrical objects such as:

  • Cylindrical water tanks or wells
  • Culverts
  • Perfume or chemical bottles
  • Cylindrical containers and pipes
  • Cylindrical flasks used in chemistry labs

Cylinder volume formula

The formula for the volume of a cylinder is given as:

Volume of a cylinder = πr2h cubic units

Where πr2 = area of a circle;

π = 3.14;

r = radius of the circular base and;

h = height of a cylinder.

For a hollow cylinder, the volume formula is given as:

Volume of a cylinder = πh (r12 – r22)

Where, r1 = external radius and r2 = internal radius of a cylinder.

The difference of the external and internal radius forms the wall thickness of a cylinder i.e.

Wall thickness of a cylinder = r1 – r2

Let’s solve a few example problems about the volume of cylinders.

Example 1

The diameter and height of a cylinder are 28 cm and 10 cm, respectively. What is the volume of the cylinder?

Solution

Given;

The radius is half of the diameter.

Diameter = 28 cm ⇒ radius = 28/2

= 14 cm

Height = 10 cm

By the cylinder volume formula;

volume = πr2h

= 3.14 x 14 x 14 x 10

= 6154.4 cm3

So, the volume of the cylinder is 6154.4 cm3

Example 2

The depth of water in a cylindrical tank is 8 feet. Suppose the radius and height of the tank are 5 feet and 11.5 feet, respectively. Find the volume of water required to fill the tank to the brim.

Solution

First calculate the volume of the cylindrical tank

Volume = 3.14 x 5 x 5 x 11.5

= 902.75 cubic feet

Volume of water in the tank = 3.14 x 5 x 5 x 8

= 628 cubic feet.

The volume of water required to fill the tank = 902.75 – 628 cubic feet

= 274.75 cubic feet.

Example 3

The volume of a cylinder is 440 m3, and the radius of the base is 2 m. Calculate the height of the tank.

Solution

Volume of a cylinder = πr2h

440 m3 = 3.14 x 2 x 2 x h

440 = 12.56h

By dividing 12.56 on both sides, we get

h = 35

Therefore, the height of the tank is 35 meters.

Example 4

The radius and height of a cylindrical water tank are 10 cm and 14 cm, respectively. Find the volume of the tank in liters.

Solution

Volume of a cylinder = πr2h

= 3.14 x 10 x 10 x 14

= 4396 cm3

Given, 1 Liter = 1000 cubic centimeter (cm3)

Therefore, divide 4396 by 1000 to get

Volume = 4.396 liters

Example 5

The external radius of a plastic pipe is 240 mm, and the internal radius is 200 mm. If the pipe’s length is 100 mm, find the volume of material used to make the pipe.

Solution

A pipe is an example of a hollow cylinder, so we have

Volume of a cylinder = πh (r12 – r22)

= 3.14 x 100 x (2402 – 2002)

= 3.14 x 100 x 17600

= 5.5264 x 106 mm3.

Example 6

A cylindrical solid block of a metal is to be melted to form cubes of edge 20 mm. Suppose the radius and length of the cylindrical block are 100 mm and 490 mm, respectively. Find the number of cubes to be formed.

Solution

Calculate the volume of the cylindrical block

volume = 3.14 x 100 x 100 x 490

= 1.5386 x 107 mm3

Volume of the cube = 20 x 20 x 20

= 8000 mm3

The number of cubes = volume of the cylindrical block/volume of the cube

= 1.5386 x 107 mm3/ 8000 mm3

= 1923 cubes.

Example 7

Find the radius of a cylinder with the same height and volume as a cube of sides 4 ft.

Solution

Given:

Height of cube = height of cylinder = 4 feet and,

volume of the cube = volume of cylinder

4 x 4 x 4 = 64 cubic feet

But volume of a cylinder = πr2h

3.14 x r2 x 4 = 64 cubic feet

12.56r2 =64

Divide both sides by 12.56

r2 = 5.1 feet.

r = 1.72

Therefore, the radius of the cylinder will be 1.72 feet.

Example 8

A solid hexagonal prism has a base length of 5 cm and a height of 12 cm. Find the height of a cylinder with the same volume as the prism. Take the radius of the cylinder to be 5 cm.

Solution

The formula for the volume of a prism is given as;

Volume of a prism = (h)(n) (s2)/ [4 tan (180/n)]

where, n = number of sides

s = base length of a prism

h = height of a prism

Volume = (12) (6) (52)/ (4tan 180/6)

=1800/2.3094

=779.42 cm3

Volume of a cylinder = πr2h

779.42 =3.14 x 5 x 5 x h

h = 9.93 cm.

So, the height of the cylinder will be 9.93 cm.



Practice Questions

1. The radius and height of a cylinder are $5$ cm and $16$ cm, respectively. What is the volume of the cylinder? Use $\pi \approx 3.14$.

2. The diameter and height of a cylinder are $14$ ft and $12$ ft, respectively. What is the volume of the cylinder? Use $\pi = \dfrac{22}{7}$.

3. If the cylindrical paint box’s volume and radius are $640\pi$ cubic cm and $8$ cm, respectively, what is its height?

4. Consider a cylindrical tank whose height is two times its radius. If the volume of the tank is $1728\pi$ cubic units, what is the radius of the tank?

5. The external radius of a plastic pipe is $120$ mm, and the internal radius is $80$ mm. If the pipe’s length is $50$ mm, what is the volume of material used to make the pipe? Use $\pi \approx 3.14$.
